Deep Well Pump (Submersible)
- 164' 1/2" Max. Head Height - 1188 GPH
Product Video
General Description
Deep Well Pump (Submersible) - 164' 1/2" Max. Head Height - 1188 GPH
The deep well pump is submersible, and is single phase with 0.5 horsepower. The water pump is constructed out of corrosion-resistant materials.
Function
The open well submersible pump is placed inside a well casing. The pump uses a centrifugal pump and impellers to pull water into the intake, pushing it through pipes to a desired location.
Function
The open well submersible pump is placed inside a well casing. The pump uses a centrifugal pump and impellers to pull water into the intake, using water pressure to push it through pipes to a desired location.
Applications
The open well submersible pump and similar types of pumps can be used in wells, fountains, sewer systems, and any context where water needs to be pulled to the surface. The pump features allow it to be extremely versatile.
Technical Details
| Certifications: | SGS, TUV, ISO, CE |
|---|---|
| Max Output Power: | 0.5 HP |
| Outlet Size: | 1 1/4 inch |
| Model: | Single Phase |
| Voltage: | 110 V/60 Hz |
| Amperage: | 6.6A |
| Cable Length: | 4' 11 1/16" |
| Casing Diameter: | 4" |
| Maximum Discharge Flow: | 1188 GPH |
| Flow/ Head Performance Curve | |
| Head Height @ 0 GPM: | 164' 1/2" |
| Head Height @ 2 GPM: | 154' 2 13/32" |
| Head Height @ 3 GPM: | 150' 11 1/32" |
| Head Height @ 4 GPM: | 147' 7 21/32" |
| Head Height @ 7 GPM: | 137' 9 17/32" |
| Head Height @ 9 GPM: | 121' 4 11/16" |
Do you have a question about this product?
Deep Well Pump (Submersible) - 426' 6 1/8" Max. Head Height - 1584 GPH The deep well pump is submersible, and is single phase with 2 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Deep Well Pump (Submersible) - 193' 6 27/32" Max. Head Height - 2376 GPH The deep well pump is submersible, and is single phase with 2 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Deep Well Pump (Submersible) - 183' 8 23/32" Max. Head Height - 1848 GPH The deep well pump is submersible, and is single phase with 1.5 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Negative Pressure Duct - 8" (Diameter) * 16 ft (Length) The 8” in diameter negative pressure proof duct has a length of 16 feet and is made out of a PVC material. It can endure negative pressure of 8000pa. Function The duct connects creates...
Deep Well Pump (Submersible) - 124' 8 1/16" Max. Head Height - 1848 GPH The deep well pump is submersible, and is single phase with 1 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Deep Well Pump (Submersible) - 318' 2 29/32" Max. Head Height - 1188 GPH The deep well pump is submersible, and is single phase with 1.5 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Deep Well Pump (Submersible) - 229' 7 29/32" Max. Head Height - 1188 GPH The deep well pump is submersible, and is single phase with 0.75 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Deep Well Pump (Submersible) - 469' 1 15/16" Max. Head Height - 4488 GPH The deep well pump is three phase with 5.5 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well submersible pump is...
Deep Well Pump (Submersible) - 164' 1/2" Max. Head Height - 1188 GPH The deep well pump is submersible, and is single phase with 0.5 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Deep Well Pump (Submersible) - 364' 2 1/16" Max. Head Height - 1848 GPH The deep well pump is submersible, and is single phase with 2 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Deep Well Pump (Submersible) - 469' 1 15/16" Max. Head Height - 2376 GPH The deep well pump is submersible, and is three phase with 4 horsepower. The water pump is constructed out of corrosion-resistant materials. Function The open well...
Flameproof Duct - Ventilation Diameter 8" - Length 16 ft The flameproof duct has a ventilation diameter of 8", a length of 16 ft, and is made out of a PVC material. This flameproof equipment is able to endure temperatures between -4°F and...
what is the GPM at 140Ft.
Hello Gary, thank you for your question. At 140 feet, our D1156310 deep well pump will pump at about 20 GPM. We have quite a few models of deep well pumps that will pump at different GPM at that depth. If this one doesn't fit your needs, please check out our other deep well pumps, or give our customer service team a call and they can help point you in the right direction.
Do you have any deep well pumps to fit 2 in well casing
For a deep well submersible pump to fit 2" well casing, our factory price would be $10,000USD. The pump would be 220V/127V, with a max output power of 0.5HP. Please contact us for more information.
Will this product fit in a 4 inch well casing?
Hello Wayne, thank you for your question. This D1156310 deep well pump is 4 inches in diameter, so it will not fit in a 4 inch well. The well would need to be a minimum of 5 inches in diameter. We do not have any deep well pumps that will fit a 4 inch diameter well, but we can manufacture a custom size if you give us a call.
wiring diagram?
Hello Donna, thank you for your questions. A wiring diagram is provided with each our deep well pumps. We can certainly provide a wiring diagram, however, cannot attach it to our Q&A section. Please provide us your email or contact us via email and we will be more than happy to share the diagram.
Does this D1156347 pump and motor come with a control box? If not do you sell the control box for the 5.5 hp model?
Because the control box is an optional part of our pumps, it is sold separately and upon request. Please contact our customer support at 1-888-667-5776 and give us the specifications of your model to get your order started.
these are deep water pumps .. with only 2.5 meters of cable ?
Hello Roy, thank you for your question. That is correct, or deep well pumps only come with a lead cable and the rest of the wiring must be provided by the end user or the installer of the pump.
This pump is 110 Volt! where are the 300 ft head 220-240 volt pumps?
Our factory would be able to make a 220-240V deep well submersible pump in this single phase model. Please contact our support for more information.
How many wires to connect the D1156310 pump? How much to ship to Grande prairie alberta? Delivery time?
Hello Donna, thank you for your question. The cable comes with one 1.5 meter lead that has 3 wires. For shipping within Canada please contact our location in Calgary for shipping rate and delivery timetable.
Hi! Did pump #D1156310 come with 160 feet off the wire? I'm trying to get a solid system that will work with a 4500 kw inverter and 7000 kw generator?
Hi Rheal! Item #D1156310 does come 160 feet off the wire! Thanks for your question.
Good evening, I would like to know if this D1156367 pump can be inserted in a 2.5-inch casing or if you are so kind to tell me what diameter this pump has?
The D1156367 deep well submersible pump cannot be inserted to 2.5-inch casing. It is designed for 4 inch casing. Unfortunately, we do not supply pumps that could fit a 2.5 inch casing, but we do manufacturer custom products all the time. Please call us at 1-888-785-2677.
Does this pump handle 240 volts and can it manage dirty water?
Hello Jim, thank you for your question. This D1156312 pump cannot handle 240V as it is 110V. We do offer 240V deep well pumps, but they are not recommended for dirty water.
We are looking for a deep well submersible pump to keep our ponds aerated and cool during the summer. This would be used in a remote area without hydro so would need to run off a generator. It is a drilled well approx. 200 feet deep, our current pump is approx. 30 feet deep and is solar but isn't doing the job. We are thinking the D1156344 pump would work and we would place it at about 50 feet. How many gpm would we be getting and will this pump work off a generator and how many watt generator would it need to run?
D1156344 can get approximately 60-65gpm at 50 feet deep. With refererce to 21A/110v, it needs 2300w or above to run.
Can I use a 1 to 3 phase inverter to drive this D1156373 pump and vary the output? Thank you in advance.
Sorry, our deep well pumps, including D1156373, cannot have their output varied, as they contain a controller inside of them.
I'm looking for a thin submersible pump and don't see the case diameters. How large (long and wide) is the D1156311? THanks.
Hello David, thank you for your question. The diameter of this pump is 3 3/4" and the length of the pump is 29 1/2". This deep well pump should be installed in a deep well no smaller than 4" in diameter. If you have any other questions please do not hesitate to contact our customer support team.
I Pulled a 3" pump from my well - I tried a 4" would only go 75 ft+/- Do you have 3" submersible 05hp? - my well is 155ft.
Hi Maggie, thanks for your question. Yes, we do. D1156311 would likely work great for your well. Contact our sales team for further assistance at 1-888-667-5776 or email at sales@deelat.com!
Can I use a 1 to 3 phase inverter to drive this D1156373 pump and vary the output? Thank you in advance. Sorry, our deep well pumps, including D1156373, cannot have their output varied, as they contain a controller inside of them. To control psi, I think you can vary the output? Is that correct?
Hi Joseph. Our deep well pumps, including D1156373, cannot have their output varied, as they contain a controller inside of them. If you have any other questions, please do not hesitate to contact our customer support team.
Thinking of using your Deep Well Pump - 238 M - Single Phase - 3 HP for watering a plot 100m x 100m, all on level ground. 32mm pipe around the outside and 25mm in 18 rows. 16 sprinklers per row. He he, do you think it will do the job. I suspect it won't and will have to devide the plot into smaller sections. I know this info is not really enough but was just looking for your opinion.Thanks, best regards, Mark
Hello Mark, thank you for your questions. You are correct the information you provided is not enough to determine whether or not this deep well pump would be powerful enough to water the entire plot. What is the depth of the well? Please contact our customer support staff to speak to one of our representatives to get a better understanding of your project. We offer an array of deep well pumps in single phase and three phase and ranging in Horsepower. We certainly offer a pump that will get the job done.
Will this product be able to supply water to a 2700 sg ft home, 2 1/2 bath and some irrigation at a depth of 400' ?
This deep well pump might be able to supply your home, but we would need to know more information. What is the per capita water usage? What are your flow irrigation needs? What is the distance from the water to the top of the building? If we cannot determine the amount of water you are using in your home, we cannot know for sure if this D1156311 pump will be compatible. Please contact our customer service for assistance.
I'm in need of a solar deep well pump. I need it to pump from 204 meters or 670 ft. Do you sell this product?
Hi Mamadou. The D1156358 pump would be suitable for your needs. The pump features allow it to be extremely versatile. Please contact our wonderful customer service team for additional information.
What is the diameter of the D1156358 pump? I am looking for a 3 in DIA. submersible deep well pump the best email to reach me is murrayddavid@gmail.com
Hello David, thank you for your question. The diameter of the D1156358 pump is 4 inches. If you have any other questions or concerns please do not hesitate to ask.
How is the max amp ran?
The pump has a max output power of 0.5HP. Please contact us for more information.
